The SBPILED indicator is part of the Dupline® Carpark system, which contains other variants of sensors, controllers and displays.

The SBPILED indicator has to be installed outside the parking bay, in the driving lane.

It is used together with the SBPSUSL sensor if the sensor LEDs are not visibile from the lane side.

The LED colours to use for status indication are freely configurable, and they can be changed in daily operation through the UWP 3.0 configuration software. Typically, green is used for “vacant”, red is used for “occupied”, blue is used for “disabled people” and amber is used for “booked”.

Each sensor needs to be connected to the Dupline® 3-wire bus.

The bus provides power and enables the sensors to transmit the status to the carpark controller UWP 3.0 / SBP2CPY24, which keep track of the number of available parking spaces in an area and shows the result on the connected displays.

Benefits

• Easy and fast installation

• Automatic temperature compensation

• Clearly visible LED indication in a 360° visual angle

• Select between 8 LED colours to indicate for instance “vacant”, “occupied”, “booked”, “disabled people”

• Straightforward commissioning: programming and test by using the configuration software

Features
