This is a family of inexpensive general purpose diffuse reflective sensors with background suppression in industrial standard 18 mm cylindrical ABS housing.

The sensors are useful in applications where high-accuracy detection as well as a small size is required.

Compact housing and high power LED for excellent performance-size ratio. The potentiometer used for adjustment of the sensitivity makes the sensors highly flexible.

The output type is NPN or PNP and the output switching function is NO and NC.

Features

• Miniature sensor range

• Range: 200 mm

• Sensitivity adjustment by potentiometer

• Modulated, red light 625 nm • Supply voltage: 10 to 30 VDC

• Output: 100 mA, NPN or PNP preset

• Make and break switching function

• LED indication for output and power ON

• Protection: reverse polarity, short circuit and transients

• Cable and plug versions

• Excellent EMC performance • Excellent colour matching
