Dupline® Channel Generator with the function of a DeviceNet slave. This means that the 128 Dupline® I/O’s can be read/controlled by DeviceNet masters (PLC’s, PC interface cards, etc. from various suppliers). Several Dupline® gateways can be connected to the same DeviceNet network

Features

• Built-in Dupline® channel generator

• DeviceNet slave

• DeviceNet communication speed of up to 500 kBaud

• Read/control of 128 Dupline® inputs/outputs through DeviceNet

• Split-I/O mode selectable (128 inputs and 128 outputs)

• Support of 3 1/2 digit BCD and AnaLink analog formats

• All Dupline® formats (except 8 bit binary multiplexed) available on the DeviceNet network

• For mounting on DIN-rail (EN 50 022)

• LED indicators for supply, Dupline® carrier and fault

• AC power supply
