Superior Adaptability even to a Hostile Environment as Vibration, Impact, Storm, Intense Cold and Severe Heat

External Diameter :

Ø167~285mm

Height :

229mm

Voltage :

DC12V,24V

• Strong against Vibration and Impact and using semi-permanent LED as light source.
• Improving airtightness due to additional tightening system at upper part of the lens and extra control PCB box.
• Emitting high visible flashing light by adapting 14EA LED revolving system.
• Possible to maintain see-through in hostile environment by adopting special-coated lens.
• Improving outdoor visibility by adopting indivisual diffusion lens in each LED kit and counterlight exclusion system.
• Suitable for police car, fire engines, ambulance car, patrol car, road repair car, tow car and emergency A/S car.
• Speaker(Built-in) Volume : 130dB/m
• Lens Color :   Blue-Red ,  Red-Red ,  Amber-Amber ,  Green-Green
• Material : Lens : PC , Speaker Cover : SUS304, Reflector – PC , Board – AL
• Certificate : CE
• Protectionj Class : IP56
• Product of total length 1700mm andr other lengths are available under custom made.

Product Specification

Model	Rated Voltage	Current	Weight	Flashes	Color
ELV-LR	DC12V	1.85A	13.4Kg	60~80/min	Blue-Red  Red-Red  Amber-Amber  Green-Green
	DC24V	1.90A	13.4Kg

Available Specification
