S60ADL LED Steady/Flashing Signal Light with Bulit-in Buzzer

Add To Enquiry
Enquiry
Back To Listing
Loading...

Description

Compact Product with Integrated Light and Buzzer for Multi-Signal Transmission

Key Features:

  • External Diameter: Ø70mm
  • Height: 233mm
  • Voltage Options: DC 12V, 24V; AC 110V, 220V
  • Operation: LED steady/flashing type with a built-in strong sound buzzer
  • Signal Transmission: Capable of transmitting both visual and audible signals simultaneously
  • Design: Compact, attractive, and easy to install in limited spaces
  • High Visibility: Excellent light diffusion with a high-quality lens
  • Durability: Suitable for machines with strong vibration and impact
  • Customization: Built-in switch to select between steady or flashing operation
  • Lens Colors: Red (R), Amber (A), Green (G), Blue (B)
  • Flashes: 60~80/min
  • Material: Lens – AS, Body – ABS
  • Protection Class: IP54
  • Maximum Volume: 100 dB/m (Custom 2 Buzzer sound type available)

Product Specifications:

Model Rated Voltage Current Weight Color
S60ADL DC 12V 0.120A 0.21Kg R – Red, A – Amber, G – Green, B – Blue
DC 24V 0.110A 0.21Kg
AC 110V 0.030A 0.36Kg
AC 220V 0.015A 0.36Kg

Sound Tone Combination of Standard Product:

Item Sound Tone Voltage Volume
1 Buzzer Sound Continuous “Turu~” AC, DC MAX 100dB
Intermittent sound also available

Wiring:

  • Power Line:
    • Output: UL1015 NO.18(0.75sq) x 2C 400mm
    • DC Product: Black line is Negative (-)



Available Specifications:

Model Voltage Color
S60ADL 12-DC12V R – Red
24-DC24V A – Amber
110-AC110V G – Green
220-AC220V B – Blue
