Description
FEATURES
- 3-Phase,3-Wire method
- High performance under small leakage current
- Efficient performance under motor noise
- High filterings by double filters
- Excellent Filtering for Normal Mode and Common Mode Noise
APPLICATIONS
- Inverter System, Aircons
- FA and OA Equipments
- Personal Computer and peripherals.
- Digital and Measuring Equipments
- Commumication Equipments
| MODEL | TWT – RC220F | TWT – RC330F |
| RATED CURRENT | 20 A | 30 A |
| RATED VOLTAGE | 450 VAC | |
| TEST VOLTAGE | 1,500V 10mA between I/O terminals and Earth for 1 minute | |
| INSULATION VOLTAGE | 500VDC 300Mohm between I/O terminals and Earth | |
| LEAKAGE CURRENT | 2 mA Max | |
| TEMPERATURE RISE | 40oC Max | |
| OPERATING TEMPERATURE | -25 ~ +85oC | |
